High Pressure Spray Bar Sweeper

Vehicle model:AUMARK-C38
Cabin:Single row/W1995/right rudder
Overall:6.7×2.1×2.28m
Wheel base(mm):3800

Tanks

volume

Water tank   volume: 1.5 square dustbin volume: 4 square

Box body material

Material of   tank: stainless steel

Dash material:   stainless steel

Sub-engine brand   and power

Isuzu Engine Co.   Ltd

Cleaning the   width

2.8-3.0m

Operation   ability

38000(m2/h)

Cleaning speed   (km/h)

15-20

Cleaning speed   (km/h)

3-15

Suction capacity

Density (g/cm3)   : 2.0 mass (kg) : 1.5 suction particle size (mm) : ≥100

Garbage box tipping   Angle

≥45°

Cleaning   efficiency

≥96%

The fan system

Special high   pressure centrifugal fan, desktop fan (maintenance free) rated working speed   2700r/min

Suction nozzle   device

The suction   nozzle is suspended between the rear wheels of the chassis car, which is   composed of a suction nozzle, a roller and a straw. The suction nozzle body   can be moved along with the suction nozzle, and the suction nozzle lifting   oil cylinder is controlled.

Scanning plate   Angle adjustment

Forward scanning   plate: forward 5°~15° outward 5°~10° rear scanning plate: forward 5°~10°   inward 5°~10

Single sweep   plate with the number of brushes

22

Vice frame

Vice beam at the   tank bottom

Q345 carbon   steel plate
